Home > Products > Neodymium Quick Links > Ring Magnets > N45 Ring Neodymium Magnets ¢35x¢24x 10 mm
N45 Ring Neodymium Magnets ¢35x¢24x 10 mm
  • N45 Ring Neodymium Magnets ¢35x¢24x 10 mm

N45 Ring Neodymium Magnets ¢35x¢24x 10 mm

    Min. Order: 1000pcs
    Delivery Time: 25 Days
Contact Now

Additional Info

Packaging: Carton/Box/Pallet

Brand: Anfeng

Place of Origin: China ,Ningbo

Product Description

Product Details: N45 Ring Neodymium Magnets ¢35x¢24x 10 mm

Ring Neodymium Magnets
Grade:N45
Size: ¢35x¢24x 10 mm (od1.378"x id0.945"x 0.393"thick).
Material: Sintered Neodymium-Iron-Boron (NdFeB)
Plating: Nickle Plated (Ni-Cu-Ni).We also can plate Zn, gold, copper, epoxy and so on .
Max Operating Temp: 80C

Ring Neodymium Magnets can be axially or diametrically magnetized.
Ring Magnets can be magnetized in different ways. The most common way is through the thickness and most of these are magnetized that way. I can also request an shape neodymium ring magnet to be magnetized through the diameter. Neodymium cannot be magnetized radially - with a pole on the outside edge and the opposite pole on the inside edge. However, if you really need neodymium ring magnets to have a radial magnetization pattern we can make them in arc segments that you can put together.

Application: microphone assemblies, computer rigid disc drives, linear actuators,hammer bank printers, magnetic separator motors,rotors, windturbines, windgenerators,loudspeakers,Magnetic Hooks, magnetic holder, filters automobiles and so on.

Looking for ideal Ring Neodymium Magnets Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Ring Neodymium Magnets are quality guaranteed. We are China Origin Factory of Ring Neodymium Magnets. If you have any question, please feel free to contact us.

Product Categories : Neodymium Quick Links > Ring Magnets
